   Cutting machine is our special machine for H beam build line, Plate cutting machine CNC40 is the perfect embodiment of the numerical control technology and precision machine,product types includes flame,plasma, single drive.double drive etc,  we will select the sort of types , the sort of plasma devices , and the function of automatic lifting ,automatic ignition ,powder marking ,initial location ï¼automatic piercing according to the customer’s requirement.
 Plate cutting machine CNC40 (CNC machine) is used in petrochemical machinery, engineering machinery, wind power equipment, construction & bridge, shipbuilding, food & pharmaceutical and other industrie
Technical data of the Machine
Length of guided rails: 8000mm Â
Track width: 3000mm Â
Effective cutting scope:  6400mmÂ
Cutting width of single torch:2400mm
Cutting speedï¼50-1000 mm/min  ( stepless adjust )
Travel speed: 6000mm/min
Cutting thickness: 6~25mm
ï¼apply in  Plasma torch , PMX125 Pierce thickness can to25mmï¼
Cutting thickness: 25~100mm ï¼when using 1Â group of flame torchesï¼
Transverse torchï¼1 CNC flame and with automatic ignition; 1 CNC plasma and with ARC Voltage THCÂ
Longitudinal torchï¼NO .
Surface quality for cuttingï¼â¥Ra12.5
Precision of the whole machine: Suitable for JB/T 5102-1999
Air proofing of the whole machine: Suitable JB/T 5101
Precision of cutting position: ±0.5mm/1000mm
CNC controller: 1Â set, CCM3
Cutting gas: Oxygen
Cutting material: Â Q235-A mild steel
Working condition: inside temperature 0-45â, relativity humidity â¤90%
Input power: 1PH AC240V/3PH AC380V 50Hz ( user specify)
